Acura RL (2005 – 2006) – wiring diagrams – oil warning
Year of production: 2005, 2006
Oil warning
WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
Year of production: 2005, 2006
WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
