Lexus GS300 (1996 – 1997) – fuse box diagram

Lexus GS300 (1996 – 1997) – fuse box diagram

Year of production: 1996, 1997

Driver’s side kick panel

Lexus GS300 - fuse box - driver's side kick panel
Lexus GS300 – fuse box – driver’s side kick panel

Engine compartment

Lexus GS300 – fuse box – engine compartment
Lexus GS300 – fuse box – engine compartment
Fuse Ampere rating [A] Circuit protected
1 SEAT HTR 15 Seat heater
2 STOP 20 Shift lock system, high mounted stoplight, cruise control system, anti–lock brake system, traction control system, multiport fuel injection system/sequential multiport fuel injection system, stop lights
3 GAUGE 15 Rear window and outside rear view mirror defogger, heater control system, air conditioning system, gauges and meters, service reminder indicators and warning buzzers (except discharge and open door warning lights), charging system, automatic transmission indicator, back-up lights, daytime running light system
4 ECU-IG 10 Shift lock system, telephone, power door lock system for passenger seat, seat belt system, anti-lock brake system, power steering control system, traction control system, cruise control system, driving pattern selector switch, tilt and telescopic control system, power antenna, electronic cooling fan system, instrument panel lights, automatic light control system, power door lock control system
5 CIG 15 Clock, air conditioning system, radio, cassette tape player, compact disc player, shift lock system, SRS, front and rear cigarette lighters, power door lock control system, power rear view mirror control system
6 TURN 10 Turn signal lights and indicator
7 WIPER 20 Windshield wipers and washer, headlight cleaner
8 PANEL 7,5 Automatic transmission indicator, heater control system, emergency flasher switch, glovebox light, rear ashtrays, clock, front cigarette lighter light, radio, cassette tape player, compact disc player, driving pattern selector switch light, instrument panel lights, daytime running lights system
9 SRS 7,5 SRS airbag
10 TAIL 10 License plate lights, parking lights, tail lights
11 MIR HTR 10 Outside rear view mirror defogger
12 FOG 15 Fob lights
13 DRL 7,5 Vehicles sold in Canada: Daytime running light system
14 TRAC 10 Traction control system
15 DOME 10 Interior light, vanity lights, electric moon roof system, cruise control system, open door warning light, personal lights, trunk room light, door courtesy lights, footlights, ignition switch light, clock, anti-lock brake system, power antenna
16 ECU-B 7,5 Locking with wireless remote control system, anti-lock brake system, traction control system, cruise control system, daytime running light system
17 ALT SENSING 7,5 Charging system
18 AM2 15 Multiport fuel injection system/sequential multiport fuel injection system, SRS, charging lamp, starting system, electronic ignition system/distributor ignition system, gauges and meters, service reminder indicators and warning buzzers (except discharge and open door warning lights)
19 TEL 15 Telephone
20 HAZ-HORN 20 Emergency flashers, horns
21 EFI 20 Electronically controlled automatic transmission system, multiport fuel injection system/sequential multiport fuel injection system
22 RADIO NO. 1 25 Radio, cassette tape player, compact disc player, power antenna
23 IG2 30 Electronic ignition system/distributor ignition system
24 OBD II 7,5 On–board diagnosis system
25 HEAD RH 15 Vehicles sold in U.S.A.: Right–hand headlight
HEAD RH–UPR 10 Vehicles sold in Canada: Right–hand headlight (high
beam
26 HEAD LH 15 Vehicles sold in U.S.A.: Left–hand headlight
HEAD LH–UPR 10 Vehicles sold in Canada: Left–hand headlight (high beam)
27 HEAD RH–LWR 10 Vehicles sold in Canada: Right–hand headlight (low beam)
28 HEAD LH–LWR 10 Vehicles sold in Canada: Left–hand headlight (low beam)
29 RDI FAN 30 Electronic cooling fan system

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
