ABS control unit and sensor – ASR sensor – DSC sensor – Brake lamp switch
43
20
Windscreen wiper motor (ignition switch +)
47
20
Driver’s electric window motor
48
20
Passenger’s electric window motor
49
5
Parking sensors control unit – Audio system – Steering mounted controls – Centre and side switch panels -Auxiliary switch panel – Battery cut-off control unit (ignition switch +)
50
7.5
Airbags and pre-tensioners control unit
51
5
Tachograph – Power steering control unit – Air conditioning – Reversing lamps – Water in Diesel sensor -Air flow sensor (ignition switch +)
