Citroen Berlingo Multispace (2008) – fuse box diagram

Citroen Berlingo Multispace (2008) – fuse box diagram

Year of production: 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016

Fascia fuses

Citroen Berlingo Multispace - fuse box diagram - fascia fuses
Citroen Berlingo Multispace – fuse box diagram – fascia fuses
Fuses Ampere rating [A] Allocation
1 15 Rear wiper
2 Spare
3 5 Air bag
4 10 Air conditioning, diagnostic socket, mirror control, headlamp beam
5 30 Electric windows
6 30 Locks
7 5 Rear courtesy light, front map reading light, roof console
8 20 Audio equipment, CD changer, display, tyre under-infl ation detection, alarm and siren
9 30 Front and rear 12 V socket
10 15 Central column
11 15 Low current ignition switch
12 15 Rain and brightness sensor, air bag
13 5 Instrument panel
14 15 Parking assistance, automatic air conditioning controls, hands-free kit
15 30 Locks
16 Spare
17 40 Rear screen/mirrors de-icing



Fuse box in passenger compartment

Citroen Berlingo Multispace - fuse box diagram - passenger compartment
Citroen Berlingo Multispace – fuse box diagram – passenger compartment
Fuses Ampere rating [A] Allocation
1 Spare
2 20 Heated seats
3 Spare
4 15 Folding mirrors relay
5 15 Refrigeration equipment socket relay



Fuse box under the bonnet

Fuses Ampere rating [A] Allocation
1 20 Engine management
2 15 Horn
3 10 Front and rear wash-wipe pump
4 20 Headlamp wash pump
5 15 Engine components
6 10 Steering wheel angle sensor, ESP
7 10 Brake switch, clutch switch
8 25 Starter
9 10 Headlamp beam motor, parc management unit
10 30 Engine components
11 40 Spare
12 30 Wipers
13 40 Built-in systems interface
14 30 Pump
15 10 Right-hand main beam headlamp
16 10 Left-hand main beam headlamp
17 15 Right-hand dipped headlamp
18 15 Left-hand dipped headlamp

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
