Acura SLX (1996) – wiring diagrams – headlamps

Acura SLX (1996) – wiring diagrams – headlamps

Year of productions:  1996

Headlamps

Acura SLX - wiring diagram - headlamps
Acura SLX – wiring diagram – headlamps

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
