Year of productions:  2005

Lamp out warning

Acura NSX - wiring diagram - lamp out (part 1)
Acura NSX – wiring diagram – lamp out (part 1)
Acura NSX - wiring diagram - lamp out (part 2)
Acura NSX – wiring diagram – lamp out (part 2)

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
